mesin pengering beku
1. pre-pendingin / penukar panas
2. Evaporator
3. Pemisah air soda
4. Kondensor udara
5Kondensor air
6. Kompresor pendingin
7. Pemisah gas-cairan
8. switch tegangan tinggi dan rendah
9. Filter pengeringan 10. katup ekspansi (tabung kapiler) 11. katup bypass gas panas 12. katup pengatur volume air 13. katup pembuangan otomatis 14. saklar tekanan tinggi
| pengering pendingin (jenis pendingin udara) Parameter teknis | ||||||
| Model | Pengolahan udara ((m3/menit) | Kekuatan kompresor (HP) | Sumber daya ((V/50Hz) | Diameter pipa udara | Dimensi ((panjang x lebar x tinggi mm) | Berat ((Kg) |
| BL0005 | 0.8 | 0.25 | 220 | DN20 ((G33⁄44") | 400X800X640 | 50 |
| BL0010 | 1.8 | 0.35 | 220 | DN20 ((G3⁄44") | 400X800X640 | 55 |
| BL0020 | 2.8 | 0.5 | 220 | DN25 ((G1") | 400X800X780 | 65 |
| BL0030 | 3.8 | 0.75 | 220 | DN25 ((G1") | 400X800X780 | 68 |
| BL0040 | 5.5 | 1.25 | 220 | DN40 ((G11⁄2*) | 500X860X880 | 90 |
| BL0060 | 6.8 | 1.5 | 220 | DN40 ((G11⁄2*) | 500X860X880 | 95 |
| BL0080 | 8.8 | 2 | 220 | DN50 ((G2") | 700X900X1000 | 130 |
| BL0100 | 11.5 | 2.5 | 220 | DN50 ((G2") | 700X900X1000 | 135 |
| BL0120 | 14 | 3 | 380 | DN65 ((G21⁄2") | 700X1000X1000 | 160 |
| BL0150 | 16 | 380 | 4 | DN65(G21⁄2*) | 800X1000X1000 | 165 |
| BL0200 | 22.8 | 5 | 380 | DN80(F3) | 700X1450X1160 | 250 |
| BL0250 | 28.5 | 6 | 380 | DN80(F3) | 700X1450X1160 | 300 |
| BL0300 | 35 | 8 | 380 | DN80(F3) | 1800X1000X1360 | 400 |
| BL0400 | 45 | 10 | 380 | DN100(F4) | 2000X1000X1360 | 500 |
| BL0500 | 55 | 12.5 | 380 | DN100(F4) | 2200X1100X1480 | 600 |
| pengering pendingin (jenis pendingin air) Parameter teknis | |||||||
| Model | Pengolahan udara ((m3/menit) | Kekuatan kompresor (HP) | Sumber daya ((V/50Hz) | Volume air pendingin ((m2/jam) | Diameter pipa udara | Dimensi ((panjang x lebar x tinggi mm) | Berat ((Kg) |
| BL0120W | 14 | 3 | 380 | 2.8 | DN65 ((G21⁄2") | 700X1000X1000 | 160 |
| BL0150W | 16 | 4 | 380 | 3 | DN65 ((G21⁄2") | 800X1000X1000 | 165 |
| BL0200W | 22.8 | 5 | 380 | 3.5 | DN80(F3) | 700X1450X1160 | 250 |
| BL0250W | 28.5 | 6 | 380 | 4 | DN80(F3) | 700X1450X1160 | 300 |
| BL0300W | 35 | 8 | 380 | 5 | DN80(F3) | 1800X1000X1360 | 400 |
| BL0400W | 45 | 10 | 380 | 7 | DN100(F4) | 2000X1000X1360 | 500 |
| BL0500W | 55 | 12.5 | 380 | 9 | DN100(F4) | 2200X1100X1480 | 600 |
| BL0600W | 65 | 15 | 380 | 10 | DN125 ((F5) | 2200X1100X1480 | 700 |
| BL0800W | 85 | 20 | 380 | 12 | DN150(F6) | 2300X1300X1880 | 900 |
| BL1000W | 105 | 25 | 380 | 14 | DN150(F6) | 2400X1300X2100 | 1100 |
| BL1200W | 120 | 30 | 380 | 16 | DN200(F8) | 2600X1800X2500 | 1500 |
| BL1600W | 160 | 40 | 380 | 18 | DN200(F8) | 2800X2000X2600 | 1650 |
| BL2000W | 200 | 50 | 380 | 24 | DN250 ((F10) | 3400X2100X2700 | 2000 |
| BL2500W | 250 | 60 | 380 | 24 | DN250 ((F10) | 3800X2100X2800 | 2600 |
| BL3000W | 300 | 70 | 380 | 35 | DN300(F12) | 4000X2100X2900 | 3500 |
| BL3600W | 360 | 80 | 380 | 40 | DN300(F12) | 4200X2100X3000 | 4500 |
